Vibe Coding a Full-Stack AI Chatbot Platform (Part 6): End-to-End Type Safety with tRPC

This is Part 6 of the tutorial series. If you haven’t read the earlier parts, you can start with Part 1: Introduction, or read the previous part Part 5: Authentication with Better Auth.

In Part 5, we set up authentication with Better Auth (email/password + Google OAuth). Now we need the wire that will allow our React frontend to call the NestJS backend and get the data we need.

As discussed in Part 2, tRPC is the perfect tool to help us achieve our goal of having end-to-end type safety between our React frontend and NestJS backend.

A shift in prompting strategy

Up until now, I’ve been breaking down each feature into multiple smaller prompts and steps. This approach worked well for demonstrating the thought process and making it easier to follow along. It also not long ago happened to be the recommended approach for vibe coding with AI since it’s easier for models to handle smaller tasks and steps at a time.

However, I’ve noticed the model GPT 5.2 with extra high reasoning to be reliable, even when given complex multi-part instructions. So from this part onwards, I’ll be using single, detailed prompts that describe an entire feature or use case we want to build. This approach:

  • Better leverages the model’s high reasoning capabilities
  • Reduces back-and-forth iterations
  • Lets the AI see the full picture and create a more cohesive and complete implementation
  • The tasks are still small enough to be manageable for the model and also for code review and adjustments.

Let’s see this in action with our tRPC setup.

Goal for this part

By the end of this part we’ll have:

  • tRPC routers and procedures defined in apps/api (Nest owns the API surface)
  • A small shared @ai-chatbot/trpc helpers package (router + public/protected procedures)
  • AppRouter types exported to the frontend (via @ai-chatbot/api/trpc)
  • A /api/trpc endpoint mounted in NestJS
  • A tRPC client wired into React + TanStack Query
  • Our first protected procedures: chat.create and chat.list (backed by Prisma)

The prompt

Here’s the single comprehensive prompt I used to implement the entire tRPC setup:

I want to add end-to-end type-safe API communication between my React frontend and NestJS backend using tRPC. Here’s everything I need:

1. Prisma Schema Update Update my Prisma schema to add a Chat model:

  • Use UUIDv7 for chat IDs
  • Follow my mapping conventions (@@map for snake_case table names, @map for column names)
  • Use PostgreSQL timestamptz (@db.Timestamptz) for timestamps
  • Chat belongs to a User (one user has many chats)
  • Add an index on user_id
  • Keep it minimal: id, userId, title, createdAt, updatedAt

2. Shared tRPC Helpers Package Create a new buildable workspace package at packages/trpc called @ai-chatbot/trpc:

  • Compile to dist/ (CommonJS, consistent with our other backend packages)
  • Export router, publicProcedure, and protectedProcedure
  • Export TrpcContext and ProtectedContext types
  • protectedProcedure must throw UNAUTHORIZED if there is no authenticated user in context
  • Define AuthUser, TrpcContext, and ProtectedContext types for the context (containing db and user instances)

3. NestJS Router Setup In apps/api, create a tRPC router with:

  • chat.create and chat.list as protected procedures (Prisma-backed)
  • A createContext that injects db (Prisma client) and resolves user from Better Auth cookies
  • Mount tRPC at /api/trpc in main.ts using createExpressMiddleware
  • Export AppRouter types from the API package so the web app can import them via @ai-chatbot/api/trpc

4. React Client Setup In apps/web, set up tRPC + TanStack Query:

  • Add @ai-chatbot/api as a workspace devDependency (so TS can import AppRouter)
  • Create a trpc helper typed with AppRouter from @ai-chatbot/api/trpc
  • Create a QueryClient
  • Use httpBatchLink pointing at ${VITE_API_URL}/api/trpc
  • Ensure cookies are included (credentials: "include")
  • Wrap the app in providers in main.tsx

5. UI Component Create a ChatsPanel component that:

  • Calls trpc.chat.list.useQuery() to list chats
  • Calls trpc.chat.create.useMutation() to create new chats
  • Invalidates chat.list on successful creation
  • Shows loading and error states
  • Uses the existing Button styling
  • Plug it into the authenticated branch of App.tsx

Model: GPT-5.2 (extra high reasoning)

What the AI implemented

The AI successfully implemented all five parts in a single pass:

Prisma Schema:

  • Added a Chat model under packages/db/prisma/schema.prisma with all the specified conventions

Shared tRPC Package (packages/trpc):

  • Created the directory structure with context.ts, trpc.ts, and index.ts
  • Defined AuthUser, TrpcContext, and ProtectedContext types
  • Initialized tRPC and defined router, publicProcedure, and protectedProcedure with auth middleware

NestJS Router (apps/api):

  • Added chat procedures + app router inside apps/api/src/trpc
  • Added a typed createContext
  • Mounted createExpressMiddleware in main.ts
  • Exported AppRouter types via @ai-chatbot/api/trpc

React Client (apps/web):

  • Added src/lib/trpc.ts
  • Updated src/main.tsx to include QueryClientProvider + trpc.Provider

UI Component:

  • Implemented ChatsPanel component to list chats and create new ones using tRPC hooks

At this point we should be able to:

  • Log in / Sign up
  • Once logged in, see an empty chat list
  • Create a chat
  • See it appear immediately in the list

Testing checklist

  1. Start the database:

Run docker compose up -d

  1. Start apps:

Run pnpm dev

  1. In the browser:
  • Sign in
  • Click “New chat”
  • Refresh the page (list should still show, because data is persisted)

Code Quality Standards

To maintain consistent code quality and development practices across the codebase, I added the following Cursor Rules to enforce our standards:

  • Quality Checks (.cursor/rules/quality-checks.mdc): Defines required checks that must run after any code changes, including formatting, linting, and TypeScript type checking
  • Prisma Schema Conventions (.cursor/rules/prisma-schema-conventions.mdc): Ensures consistent Prisma schema patterns, including UUIDv7 IDs, PostgreSQL timestamptz types, and proper snake_case mapping

I also asked the AI to do a code review of the codebase, fixed minor issues it found and also did:

  • Add validation to env variables with zod in the @ai-chatbot/api package.
  • Add basic rate limiting to the /api/auth and /api/trpc endpoints with express-rate-limit.
  • Improve CORS configuration in the @ai-chatbot/api package.
  • Add helmet to the @ai-chatbot/api package with a basic configuration.

Next steps

We can create chats, but we still don’t have an actual “chatbot”.

In Part 7, we’ll build the core chat experience:

  • Message model + persistence
  • A chat page UI
  • Sending a message to the backend and saving it

Then we can finally plug in an LLM provider and start streaming responses.

Repository State: The current state of the codebase described in this article is available in the feat/trpc-setup branch on GitHub.
